Organize and Display Spice Jars with a Mini Spice Rack


DIY Furniture Plans to Build a Mini Spice Rack

Since I’ve really been into clean eating and cooking, I needed a way to keep my spices neatly organized. I found some tiny Mason jars at Target that were perfect for spices and I needed a a way to store them. I created the DIY furniture plans to build a Mini Spice Rack specifically for the tiny jars and the plan is also customizable for other sized jars by just changing the width, height and depth. I used decorative punched aluminum on the back and metal ribbon (purchased from Hobby Lobby) on the front to act as retainers. This is an inexpensive build that costs very little and can be completed in a couple of hours.

DIY Furniture Plans to Build a Mini Spice Rack - Featured



Materials:

  • 1-1/4″ brad nails
  • 5/8″ staples
  • Decorative punched aluminum
  • Spray paint
  • Metal ribbon and upholstery tacks (1/4″ x 1″ strips of wood can also be used)
  • Wood glue
  • Sandpaper (100, 150, 220 grits)
  • Finishing supplies (primer & paint, or stain, sealer)

Tools needed:

  • Miter saw or jigsaw
  • Pneumatic brad nailer/stapler with compressor
  • Sander
  • Metal Snips

Lumber:

  • 3 – 1/2″ x 2-1/2″ x 2′ craft boards
  • 3 – 1/2″ x 1″ x 1″ craft boards (wood rulers would be a great choice!)

Cut List:

  • 4 – 1/2″ x 2-1/2″ craft boards at 10-1/2″ – Top, Bottom & Shelves
  • 2 – 1/2″ x 2-1/2″ craft boards at 12-1/2″ – Sides
  • 3 – 1/4″ x 1″ craft boards at 11-1/2″ – Front Retainers*

(* = if not using metal ribbon)

DIY Furniture Plans to Build a Mini Spice Rack

Click on the drawings for a larger view!

Step One

Cut all of the pieces to length. Thoroughly sand each board.

Step Two

Assemble the spice rack using glue and 1-1/4″ brad nails. The top, bottom and shelves are spaced 3-1/2″ apart.

DIY Furniture Plans to Build a Mini Spice Rack - Rack

Step Three

Cut the decorative aluminum to fit the back. I raided my scraps and did not have a piece that was big enough so I used two pieces with the join behind one of the shelves. Secure the aluminum to the back using 5/8″ staples (I used a pneumatic stapler). 1/4″ plywood can also be used.

DIY Furniture Plans to Build a Mini Spice Rack - Back

DIY Furniture Plans to Build a Mini Spice Rack - Punched Aluminum

Step Four

Paint the spice rack and the retainers as desired. I used white spray paint and did not paint the retainer pieces.

Step Five

Secure the retainer pieces to the front of the shelves and bottom. If using 1/4″ wood, use glue and 1-1/4″ brad nails and if using metal ribbon, use upholstery tacks.

DIY Furniture Plans to Build a Mini Spice Rack - Retainers

DIY Furniture Plans to Build a Mini Spice Rack - Metal Ribbon Retainers

DIY Furniture Plans to Build a Mini Spice Rack - Retainer Close Up

The little jars I used measure 2″ wide by 2-1/2″ tall, and they have a chalkboard label on the top.

DIY Furniture Plans to Build a Mini Spice Rack - Jars

DIY Furniture Plans to Build a Mini Spice Rack - Completed

If resizing the plan to fit different jars or bottles, adjust the length of the shelves if necessary, and lengthen the sides to accommodate the height. For example, if the jars being used are 4″ tall, the sides will be lengthened by 4-1/2″ and the shelves will be spaced at 5″. If there are any questions about the DIY furniture plans to build a Mini Spice Rack, leave a comment below!
